Solar Panels

Solar Panels, also known as Solar Photovoltaic (PV), capture the sun’s energy using photovoltaic cells. These cells don’t need direct sunlight to work – they can still generate some electricity on a cloudy day. The cells convert the sunlight into electricity, which can be used to run household appliances and lighting.
PV cells are made from layers of semi-conducting material, usually silicon. When light shines on the cell it creates an electric field across the layers. The stronger the sunshine, the more electricity is produced. Groups of cells are mounted together in panels or modules that can either be mounted on your roof or on the ground. The power of a PV cell is measured in Watts peak {Wp}. That’s the rate at which it generates energy at peak performance in full direct sunlight during the summer. PV cells come in a variety of shapes and sizes.

null

Sova Solar 320 Watt 24 V Polycrystalline Solar Panel

null

Vikram 320 Watt 24 V Polycrystalline Solar Panel

Product Description

Brand Sova Solar
Solar Panel Type Polycrystalline
Wattage (WP) 320 Watt
Operating(Nomina) Voltage 24 V
Number of cells 72 Cells
Manufacture Warranty 12 Years
Performance Warranty 25 Years
MNRE Approved Yes
Module Efficiency (%) 16.67%
Open Circuit Voltage(Voc) 45.01 V
Short Circuit Current 9.11 A
Frame Material Aluminium
Model Number SS320P
Certifications and Approvals IEC 61215 ED2, IEC 61701, IEC 61730, IE 62804 (PID), ISO 9001-2098, ISO 14001 – 2004
Encapsulate Yes
Model Number SS320P
Weight in KG 19.5 KG
Country of Origin Made in India

FEATURES

☀ Excellent Power Output with +ve Tolerance upto 4.9Wp
☀ 12 Years Limited Product Warranty
☀ 25 Years of linear Power Guarantee
☀ High Performance Modules with efficiency up to 16.67%
☀ All the Modules are PID resistant
☀ F.S.I (Flame Spread Index) tested modules first in India
☀ 100% EL Tested
☀ The panels are constructed with Anti Reflective Coating (ARC) toughened low iron, textured high light transmission glass.
☀ Multi-layer tedlar and Fast Cure EVA
☀ Reinforced anodized Aluminium Frame
☀ Pre-drilled frame for easy mounting IP65
☀ IP67 rated junction connector solar
☀ MC4 compatible connector

APPLICATIONS

☀ On-grid system
☀ BIPV
☀ Solar Farms
☀ Standalone (Off-Grid)
☀ Systems

CONSTRUCTIONAL CHARACTERISTICS

☀ Frame
☀ Glass
☀ EVA
☀ Cells
☀ Black Sheet

CERTIFICATION

☀ IEC 61215 & 61730
☀ IEC 61701 (Salt Mist Test)
☀ IEC 62804 (PID)
☀ MNRE (India) Certified

Product Description

Brand Vikram
Solar Panel Type Polycrystalline
Wattage (WP) 320 Watt
Operating(Nomina) Voltage 24 V
Number of cells 72 Cells
Manufacture Warranty 10 Years
Performance Warranty 27 Years
Module Efficiency (%) 16.49%
Open Circuit Voltage(Voc) 46 V
Short Circuit Current(Isc) 9.03 A
Voltage at Maximum Power(Vmp/Vmpp) 34.8 V
Current at Maximum Power (Imp/Impp) 6.82 A
Frame Material Anodized Aluminium frame with twin wall profile
Model Number ELDORA GRAND
Certifications and Approvals IEC 61215 ED2, IEC 61701, UL 1703, IEC 60068-2-68, IEC 62804
Weight in KG 19.5 KG
Country of Origin Made in India

FEATURES

☀ Maximum system voltage increased to 1500V DC (IEC & UL), increased string length, low BOS cost
☀ Extremely reliable product suiting harsh environment conditions withstanding 2400 Pa Wind load, 5400 Pa Snow load.
☀ Higher output of module power by reducing cell to module power loss.
☀ Range – 315-340 W
☀ Efficiency up to 17.52%
☀ Certified for Sand and Dust test
☀ Certified for Ammonia resistance and excellent and-PID performance.
☀ Designed for very high area efficiency ideally suited for rooftop and ground mounted applications
☀ 10 Years of product warranty and 27 years of linear performance warranty
